EAN: 4260608588133
ECO-128B-WW (7200lm, 2700K)
Description
LED Strip 24V 5m Role Warmwhite 2700K SMD2835 60W 640 LEDs 6000lm Flexible LED Strip
ECO-128B-WW
Flexible LED Strip 5 m Role
128 LEDs/m, 120 lm/W, 12 W/m, 24 V, 2700 K
LED Strip 24V 5m Role Warmwhite 2700K SMD2835 60W 640 LEDs 6000lm Flexible LED Strip
Technical Data
| Model | ECO-128B-WW |
| LED type | SMD 2835 |
| Operating voltage | 24 Vdc (constant voltage) |
| LED quantity | 640 (128 LEDs/m) |
| Power | 60 W (12 W/m) |
| Efficiency | 120 lm/W |
| Light flux | 7200 lm (1440 lm/m) |
| CRI | > 80 Ra |
| Color temperature | 2700 K |
| Length | 5000 mm |
| Width | 10 mm |
| Hight | 1.2 mm |
| Life time | > 30.000 h |
| Operating temperature (tc) | -25 °C … +80 °C |
| Storage temperature | -40 °C … +100 °C |
| Protection type | IP20 |
| CE / RoHS | yes |
| Energy efficiency class | D (by regulation EU2019/2015) |
LED Strip 12V 5m Role Warmwhite 2700K SMD2835 60W 640 LEDs 6000lm Flexible LED Strip
Dimension
LED Streifen 12V 5m Rolle Warmweiss 2700K SMD2835 60W 640 LEDs 6000lm Flexibler LED Strip
Connection instructions
LED Strip ECO-128B-WW: Flexibler LED-Streifen 24 V Konstantspannung, 2700 – 3000 K Kaltweiß, 2835 SMD LED, 640 LEDs (128 LEDs/m), 5 Meter.
LEISTUNG & EFFIZIENZ: Leistung 60 W (12 W/m), Lichtstrom 6000 lm (1200 lm/m), Effizienz 120 lm/W, CRI > 80 Ra.
INSTALLATION: Breite 8 mm, Höhe 1,2 mm, Abschnittslänge 62,5 mm, Schutzart IP20, geeignet für Möbeleinbau (Küche, Möbel, Spiegel etc).
QUALITÄT: Prüfzeichen CE, Lebensdauer > 30.000 Stunden, Betriebstemperatur -25 – +80 °C, Lagertemperatur -40 – +100 °C.
LIEFERUNG: 1 x 5 Meter LED-Streifen Rolle ohne LED-Netzteil oder andere Zubehöre.
led streifen strip leiste warmweiss 2700k 3000k 5m 24v 60w ip20 möbeleinbau dimmbar smd 2835
